Linksys LGS328PC 24Port Managed Gigabit PoE + Switch with 4 1G SFP Uplinks 250W

Main Features:

• 250W PoE+ Power Budget
• Static routing
• Internet Group Management Protocol (IGMP) Multicast
• 802.1q VLAN Tagging
• Access Control List (ACL)
• Command Line Interface (CLI) Access support
• 802.1x RADIUS Authentication
• Port Mirroring
• Link Aggregation
• Port Security
• 802.1p Quality of Service (QoS)
• Bandwidth and Storm Control
• Can be rack-mounted
• External power cord
• Dimensions:  440 mm x 260 mm x 44 mm
• Weight:  3,334.8 g

Hardware

• 24 gigabit ports
• Four SFP 1 Gbps uplink ports (25F, 26F, 27F and 28F)
• One CONSOLE port
• One AC LINE power port
• LED MODE button – Push to toggle between LAN or PoE mode display.
• RESET button – Press and hold for more than 10 seconds to reset the switch to factory defaults.

Indicator Lights

To learn more about the light behavior of the Linksys LGS328PC, click here.

• POWER
• FAULT
• PoE MAX
• PoE MODE
• LAN MODE
• SPEED
• LINK/ACT

Browser Setup Requirements

• Latest Google Chrome™ (minimum version 80.0 or later)
• Latest Firefox® browser (minimum version 72.0 or later)

Package Contents

• Linksys LGS328PC
• Quick start guide
• Rack mounting kit and eight screws
• Four rubber feet
• Power cord (Internal Power Supply:  AC power 100V–240V AC at 50–60 Hz, 4.0A)
