D Link DES-1050G 48-Port Unmanaged Ethernet Switch with 2 Gigabit Copper/SFP Ports

Last updated: 25-09-2023
Item code: G1235GA
- Part No. DES-1050G/E
Description for D-Link DES-1050G 48-Port Unmanaged Ethernet Switch With Copper Gigabit Uplinks | DES-1050G
The 50-port D-Link DES-1050G unmanaged switch is designed to meet the needs of the most demanding workgroup and departmental connectivity requirements. A reliable, easy-to-use switch without the complexity of management, the DES-1050G provides (48) 10/100 BASE-TX ports plus (2) 10/100/1000BASE-TX ports. This all-in-one solution economically integrates gigabit technology, helping to remove server bottlenecks and speed up access to the network backbone. The DES-1050G combines ease of use with unsurpassed performance resulting in an exceptional value for any cost-conscious network administrator who wants the best possible solution at the best possible price.
Ease of Use
The DES-1050G is a true Plug-and-Play device with features such as Auto Speed Sensing, allowing it to automatically sense whether a network device is running at 10Mbps or 100Mbps then automatically adjusting itself for optimal performance, Auto Negotiation (Full or Half Duplex) negotiating and running the highest supported transmission rate whether in Half or in Full-Duplex, and Auto MDI/MDIX Crossover offering auto-negotiating MDI/MDIX detection on every port to eliminate the need for crossover cables or uplink ports.
Superior Performance
The DES-1050G features a non-blocking wire-speed architecture with an 13.6Gbps switching capacity for maximum data throughput. With wire-speed filtering and Store-and-Forward switching, the DES-1050G also maximizes network performance while minimizing the propagation of bad network packets.
Quality of Service
The DES-1050G supports 802.1p Quality of Service (QoS). QoS assists in the prompt delivery of time sensitive data such as voice, video, and gaming traffic. When frames enter the switch with 802.1p priority tags, they are automatically placed in one of four built-in hardware queues. Frames with higher priority tags are then passed through the switch more efficiently, helping eliminate jitter and lag in VoIP and multimedia traffic.
General features
Standards
– IEEE 802.3 10BASE-T Ethernet
– IEEE 802.3u 100BASE-TX Fast Ethernet
– IEEE 802.3ab 1000BASE-T Gigabit Ethernet
– ANSI/IEEE 802.3 Nway auto-negotiation
– IEEE 802.3x Flow Control
Number of Ports
– 48 10/100BASE-TX ports with auto MDI/MDIX
– 2 10/100/1000BASE-T ports with auto MDI/MDIX
Full/Half Duplex Support
– Ethernet/Fast Ethernet: full/half duplex
– Gigabit: full duplex
Flow Control
– Half duplex mode: back pressure
– Full duplex mode: 802.3x flow control
LED Report
– Per device: Power
– Per port: Link/Act
Switch Fabric
13.6Gbps
Transmission Method
Store-and-forward
MAC Address Table
8K entries per device
MAC Address Learning
Automatic update
RAM Buffer
3.2MBit per device
Packet Filtering/Forwarding Rate
– 10BASE-T : 14,880 pps per port
– 100BASE-TX: 148,800 pps per port
– Gigabit: 1,488,000 pps per port
Brand
D-LINK
