H8C 4 MP

Last updated: 02-06-2023
Model: H8C 4 MP
Item Code: G1220GA
- Image Sensor1/2.7″ Progressive Scan CMOS
- Lens4mm @ F2.0, viewing angle: 46° (Vertical), 89° (Horizontal),
- 104° (Diagonal) 6mm @ F2.0, viewing angle: 28°
- (Vertical), 52° (Horizontal), 60° (Diagonal)
Specifications: |
|
---|---|
Model | Model CS-H8c (1080P) |
Camera | |
Image Sensor | 1/2.7″ Progressive Scan CMOS |
Shutter Speed | Self-adaptive shutter |
Lens | 4mm @ F2.0, viewing angle: 46° (Vertical), 89° (Horizontal), 104° (Diagonal) 6mm @ F2.0, viewing angle: 28° (Vertical), 52° (Horizontal), 60° (Diagonal) |
PT Angle | Pan: 350°, Tilt: 80° |
Minimum Illumination | 0.5 Lux @ (F1.6, AGC ON), 0 Lux with IR (Data is obtained from EZVIZ laboratories) |
Lens Mount | M12 |
Day & Night | IR-Cut filter with auto-switching |
DNR | 3D DNR |
WDR | Digital WDR |
Night Vision Distance | 30 m / 98 ft |
Video & Audio | |
Max. Resolution | 1920 × 1080 |
Frame Rate | Max: 30fps; Self-Adaptive during network transmission |
Video Compression | H.265 / H.264 |
H.265 Type | Main Profile |
Video Bit Rate | Full HD; Hi-Def; Standard. Adaptive bit rate. |
Audio Bit Rate | Self-Adaptive |
Max. Bitrate | 2 Mbps |
Network | |
Wi-Fi Standard | IEEE802.11b, 802.11g, 802.11n |
Frequency Range | 2.4 GHz ~ 2.4835 GHz |
Channel Bandwidth | Supports 20 MHz |
Transmission Rate | 11b: 11 Mbps,11g: 54 Mbps,11n: 72 Mbps |
Wi-Fi Pairing | AP pairing |
Protocol | EZVIZ Cloud Proprietary Protocol |
Interface Protocol | EZVIZ Cloud Proprietary Protocol |
Wired Network | RJ45 × 1 (10M / 100M Adaptive Ethernet Port) |
Storage | |
Local Storage | MicroSD card slot (Up to 512GB) |
Cloud Storage | EZVIZ Cloud Storage (Subscription Required) |
Function | |
Smart Alarm | AI-Powered Human Shape Detection |
Customized Alert Area | Supports |
Two-way Talk | Supports |
General Function | Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark |
General | |
Operating Conditions | -30 °C to 50°C ( -22 °F to 122 °F ), humidity 95% or less (non-condensing) |
IP Grade | Weatherproof Design |
Power Supply | DC 12V / 1A |
Power Consumption | MAX. 12W |
Dimensions | 100.05 × 129.19 × 149.75 mm (3.94 × 5.09 × 5.9 inch) |
Packaging Dimensions | 140 × 140 × 192 mm (5.51 × 5.51 × 7.56 inch) |
Weight (With package) | 730 g (25.75 oz) |
Net Weight | 420 g (14.8 oz) |
In the box | |
In the box | – H8c Camera |
– Drill Template | |
– Screw Kit | |
– Waterproof Kit | |
– Power Adapter | |
– Regulatory Information | |
– Quick Start Guide |
